S0103010K
Page 14
Wheel Loader Safety
WINDOW GLASS BREAKING TOOL
This loader is equipped with a glass breaking
tool. It is on the lower side of the cab beside the
operator’s seat. This tool can be used in case of
an emergency situation which requires the
breaking of glass to exit from the operator’s cab.
Grip the handle firmly and use the sharp point to
break the glass.
WARNING!
Protect your eyes when breaking the
glass.
Model Tool Location
Mega 200-V Lower Right Side
Mega 250-V Lower Right Side
Mega 300-V Lower Left Side
Mega 400-V Lower Left Side
Mega 500-V Lower Left Side
Figure 12 LEFT SIDE
Figure 13 RIGHT SIDE
