S0607080K
Page 102
Transmission and Torque Converter
(ZF 4WG-310)
I. Introduce determined shims (see
Figure 223 to Figure 226).
J. Heat inner bearing race (spur gear
bearing) and position it against
shoulder.
K. Heat inner bearing race (spur gear
bearing) and position it against
shoulder.
CAUTION!
Use protective gloves.
CAUTION!
Use protective gloves.
Figure 229
Figure 230
Figure 231
