S0607900C
Page 11
Transmission Error Codes (ZF)
18 **
S.C. to battery voltage at
Solenoid LIS1 (Function No.
1).
TCU detected a wrong
voltage at output pin, that
looks like a S.C. to battery
voltage.
• Cable is defective and is
contacted to battery voltage.
• Solenoid LIS1 (Function No.
1) device has an internal
defect.
• Connector pin is contacted
to battery voltage.
Customer specific. Check cable from
TCU to Solenoid
LIS1 (Function No.
1) device.
Check connectors
from Solenoid LIS1
(Function No. 1) to
TCU.
Check resistance of
Solenoid LIS1
(Function No. 1)
device.
1)
See
“Measurement of
Resistance at
Actuator/sensors
and Cable” on page
35.
19 ** O.C. at Solenoid LIS1
(Function No. 1).
TCU detected a wrong
voltage at output pin, that
looks like a O.C. for this output
pin.
• Cable is defective and has
no connection to TCU.
• Solenoid LIS1 (Function No.
1) device has an internal
defect.
• Connector has no
connection to TCU.
Customer specific. Check cable from
TCU to Solenoid
LIS1 (Function No.
1) device.
Check connectors
from Solenoid LIS1
(Function No. 1)
device to TCU.
Check resistance of
Solenoid LIS1
(Function No. 1)
device.
1)
See
“Measurement of
Resistance at
Actuator/sensors
and Cable” on page
35.
1A ** S.C. to ground at Solenoid
LIS2 (Function No. 2).
TCU detected a wrong
voltage at output pin, that
looks like a S.C. to vehicle
ground.
• Cable is defective and is
contacted to vehicle ground.
• Solenoid LIS2 (Function No.
2) device has an internal
defect.
• Connector pin is contacted
to vehicle ground.
Customer specific. Check cable from
TCU to Solenoid
LIS2 (Function No.
2) device.
Check connectors
from Solenoid LIS2
(Function No. 2)
device to TCU.
Check resistance of
Solenoid LIS2
(Function No. 2)
device.
1)
See
“Measurement of
Resistance at
Actuator/sensors
and Cable” on page
35.
Fault
Code
(hex)
Meaning of the Fault Code
(Possible reason for fault
detection.)
Reaction of the
TCU
Possible Steps to
Repair
Remarks
* Only Mega 400-III PLUS
** Only Series "V"
Gray shaded boxes are error codes for other applications. They are only given for general reference purposes.
