S0607900C
Page 24
Transmission Error Codes (ZF)
94 ** S.C. to ground at relay starter
interlock.
TCU detected a wrong
voltage at output pin, that
looks like a S.C. to vehicle
ground.
• Cable is defective and is
contacted to vehicle ground.
• Starter interlock relay has an
internal defect.
• Connector pin is contacted
to vehicle ground.
No reaction.
OP-Mode: normal.
Check cable from
TCU to starter
interlock relay.
Check connectors
from starter interlock
relay to TCU.
Check resistance
1)
of starter interlock
relay.
1)
See
“Measurement of
Resistance at
Actuator/sensors
and Cable” on page
35.
95 * O.C. at LIS1 solenoid valve.
The measured resistance
value of the valve is out of
limit.
• Cable/connector is defective
and has no contact to TCU.
• Valve has an internal defect.
No reaction.
OP-Mode: normal.
Check the cable from
TCU to the valve.
Check the
connectors from
valve to TCU.
Check the valve
resistance.
If fault code 95 and
98 are both being
displayed for about
one second each,
see combined fault
code.
95 ** S.C. to battery voltage at relay
starter interlock.
TCU detected a wrong
voltage at output pin, that
looks like a S.C. to battery
voltage.
• Cable is defective and is
contacted to battery voltage.
• Starter interlock relay has an
internal defect.
• Connector pin is contacted
to battery voltage.
No reaction.
OP-Mode: normal.
Check cable from
TCU to starter
interlock relay.
Check connectors
from starter interlock
relay to TCU.
Check resistance
1)
of starter interlock
relay.
1)
See
“Measurement of
Resistance at
Actuator/sensors
and Cable” on page
35.
95 *
98 *
Each
fault
code
shown
for about
one
second.
S.C. battery voltage or ground
at LIS1 solenoid valve or LIS2
solenoid valve.
• Cable is defective and is
contacted to vehicle ground or
vehicle ground.
• Cable has no connection to
TCU.
• Valve has an internal defect.
• Connector pin is contacted
to battery voltage or is broken.
• Connector pin is contacted
to vehicle ground.
No reaction.
OP-Mode: normal.
Check the cable from
TCU to the valve.
Check the connector.
Check the valve.
---------------
Fault
Code
(hex)
Meaning of the Fault Code
(Possible reason for fault
detection.)
Reaction of the
TCU
Possible Steps to
Repair
Remarks
* Only Mega 400-III PLUS
** Only Series "V"
Gray shaded boxes are error codes for other applications. They are only given for general reference purposes.
