S0203070K
Page 5
Specifications for Mega 500-V
GENERAL SPECIFICATIONS
MEGA 500-V
Item Specification
Standard Bucket Capacity
4.8 m
3
(6.3 yd
3
)
Vehicle Weight (W/ROPS CANOPY) 28,800 (29,600) kg (63.493 (65.257) lb)
Engine
Type Cummins N14-C
Horsepower 320 ps (316 hp) / 2,100 rpm
Max. Torque 156 kg•m (1,128 ft lb) / 1,400 rpm
Transmission
Full Automatic Power -Shift Full Automatic Power Shift
Speeds 4 Forward, 3 Reverse
Brake Systems
Travel Brakes 4 Wheel, Wet Disk
Parking Brake SHAR, Dry Disc Type
Performance
Travel Speed 7 – 35 km/h (4.35 - 21.75 MPH)
Steering Angle
±
40°
Min. Tire Turning Radius 6,140 mm (242")
Safe Operating Load 8,640 kg (19,047 lb)
Max. Breakout Force 27,000 kg (59,525 lb)
Bucket Rise Time 6.5 Sec
Bucket Dump Time 1.3 Sec
Bucket Descent Time 3.4 Sec
Maximum Gradeability 30° (58%)
