Daewoo Mega 500-V - Page 611

S0709730K
Page 9
Power Steering Unit
Return to Master Table of Contents
SPECIFICATIONS
Reference
Number
Description
1 Seal Ring
2 Housing
3 Spool
4 Sleeve
5 Ball
6 Threaded Bushing
7 O-ring
8 Backing Ring (If equipped)
9 Thrust Washers
10 Thrust Bearing
11 Spacer Ring
12 Cross Pin
13 Neutral Springs
14 Shaft
15 Spacer - 13.8 mm (If
equipped)
16 Spacer - 25 mm (If
equipped)
17 Spacer Bushing (If
equipped)
18 O-ring 80.5 x 1.5 mm
19 Middle Plate
20 Distributor Plate
21 Rotor
22 O-ring - 79.92 x 1.78 mm
23 Cylinder Gear
24 End Cover
25 Washer
26 Roll Pin 2.5 x 32 mm
27 Bolt
Reference
Number
Description
Steering Unit
Specification
M300-V M400-V M500-V
Type Load Sensing, Dynamic Signal, Non-reaction
Gerotor Displacement 1,000 cc/rev
(61 cu. in./rev)
200.0 cc/rev
(12.20 cu. in./rev)
200.0 cc/rev
(12.20 cu. in./rev)
