Restriction Valve
Return to Master Table of Contents
SPECIFICATIONS
Item Specification
Maximum Rated Pressure 210.0 bar
(3,045.84 psi)
Rated Flow Ports to R1,R3,C 200
l
/min. (52.8 gpm)
Rated Flow Ports to R2 700
l
/min. (184.8 gpm)
Setting Pressure C4, 5, 6, 7 0.7
±
0.1 Bar
(10 ±1.5 psi) Cracking Pressure
Port Size
R1, R2 2" SAE Flange Port (M12, 1.75)
P1, EF, P3 1-1/4" SAE Flange Port (M12, 1.75)
HT 1" PF O-ring
TPM 1/4" PF O-ring
R3 1/4" PF O-ring (Supplied Plugged)
C 3/4" PF O-ring
