Daewoo Mega 500-V - Page 666

S0802190K
Page 21
Electrical System
Return to Master Table of Contents
Reference
Number
Description
1 Instrument Panel
2 Headlight Switch
3 Forward Lever Switch
4 Reverse Lever Switch
5 High Beam Switch
6 Left Turn Light Switch
7 Right Turn Light Switch
8 Work Light Switch
9 Emergency Steering Switch
10 Speedometer
11
Coolant Temperature
Sensor
12 Fuel Sensor
13
Transmission Oil
Temperature Sensor
14 Brake Oil Filter Switch
15
Air Cleaner Clogging
Warning Indicator
16 Engine Oil Pressure Switch
17
Coolant Temperature
Switch
18 Brake Oil Pressure Switch
19
Parking Brake Pressure
Switch
20 Alternator
21 Control Unit
22 Alarm Buzzer
23 Alarm Relay
24 Battery
25 Battery Relay
26 Circuit Breaker
27 Fuse Box
28 Fusible Link
29 Preheat Controller
Reference
Number
Description
