S0403040K
Page 3
Counterweight
SPECIFICATIONS
NOTE:
Weight
COUNTERWEIGHT
NOTE:
1) 110 kg•m (796 ft lb)
Mega 500-V 1,920 kg (4,233 lb)
AHS3700L
Figure 1
