AV7000 LINEAR CAMERA REFERENCE MANUAL
108
4
Field Name
Action/Definition
Idx
Select an option button for the row/barcode you wish to edit.
 If a barcode type is displayed in the selected row, its configuration can then be
edited.
 If a row displaying disabled is selected, a barcode type can be selected and
configured for that row.
Type
Displays the name of the barcode symbology for that index. If no symbology has
been added for a row, disabled is displayed.
Minimum
Length
Displays the minimum barcode character length for that row's symbology.
Maximum
Length
Displays the maximum barcode character length for that row's symbology.
Code n
Definition
NOTE: Input fields will vary depending on
the selected symbology.
Enable
Select the Enable check box to activate the selected barcode. Deselect the
Enable check box to disable the selected barcode. When the check box has
been selected, configuration and code type options are displayed.
Code
Symbology
Select a barcode symbology from those available in the Code Symbology
drop-down list.
Add On
EAN and UPC
Codes only
Select No Add On, 2 digits Add On, or 5 digit Add On from the Add On drop-
down list. Selecting 2 digit Add On or 5 digit Add On adds that many digits as a
supplement to the barcode. EAN is the acronym for International Article Number,
previously known as European Article Number.
Minimum
Length
Not shown on
EAN and UPC
Enter the minimum character length for the selected barcode.
Maximum
Length
Not shown on
EAN and UPC
Enter the maximum character length for the selected barcode.
Match String
Rule
Select Disable, Match, or Do Not Match from the drop-down list. This
parameter defines the matching rule, according to which a code can be
transmitted.
 Match: All codes matching the Pattern Match String will be transmitted
 Do Not Match: All codes not matching the Pattern Match String will be
transmitted
Pattern Match
String
(max. 200
chars)
Click to activate the Text Entry Tool and create a pattern match string.
A Pattern Match String allows the user to check for a sequence of characters in a
group of barcodes. The string can be made up of a sequence of alpha numeric
characters combined with Regular Expression Syntax.
