Datalogic AV7000 Reference Manual

E-GENIUS
129
4
Field Name
Action/Definition
Use Global
Configuration
Select the check box to reveal the global configuration options. When Global
Configuration is selected any of the AV7000’s in the tunnel will use this transport.
When not selected, a drop-down allows you to select a particular AV7000. This is
only available for transport 1, the only serial transport option.
Enable
Select the check box to reveal the related configuration options.
Device
Select
Select a listed named device from the drop-down list.
Data Output
Protocol
Select from the drop-down list. Once selected, the input options for that selection are
revealed. Current options for Data Output Protocol are:
 Standard
 Advanced
 Crisplant
 Beumer
 Custom 1-4
 WebSentinel
 Video Coding (PV v1.11)
 SC5000
Protocol Specialized Settings
Advanced
Advanced
Formatter
Index
Select and index number from the drop-down list. This
selection is available when Data Output Protocol >
Advanced is selected.
Crisplant
Crisplant
Protocol
Type
Select P10, CSC, or CMC from the drop-down list.
P10
The Protocol Index message syntax is fixed
according to the Crisplant P10 message
specifications.
CSC
The Protocol Index message syntax is fixed
according to the Crisplant CSC message
specifications.
CMC
The Protocol Index message syntax is fixed
according to the Crisplant CMC message
specifications.
Scanner ID
Select Datalogic NVS9000/AV7000, Accu-Sort 4800,
Accu-Sort 55/70, Accu-Sort Quad-X. Available if
Crisplant has been selected.
Heartbeat
Enable
Select the check box to enable heartbeat messages.
Heartbeat
Timeout
Enter a time value in seconds to define the amount of
time between two message transmissions. If the input
timeout expires and no transmission has occurred, the
Heartbeat message will be transmitted.
Read Mask
Enable
Select the check box to enable.
Code Type
Enable
Select the check box to enable.
