Diagnostic information 2-149
Were any of the above items recently replaced?
2
Check the system card assembly.
Was the system card assembly recently replaced?
Go to step 4. Contact next level
of support.
3
Replace the current operator panel assembly or NVM card
assembly with the original component. Go to “Operator
or go to “NVM card assembly removal” on page 4-79.
Does the error remain?
Go to step 5. Problem solved.
4
Replace the current system card assembly with the original
system card assembly.
Go to “System card assembly removal” on page 4-76.
Does the error remain?
Go to step 6. Problem solved.
5
If problem continues, replace the original operator panel
or go to “NVM card assembly removal” on page 4-79.
Does the error continue?
Contact the next
level of support.
Problem solved.
6
If the problem continues, replace the original system card
assembly with a new and not previously installed
component.
Go to “System card assembly removal” on page 4-76.
Contact the next
level of support.
Problem solved.
panel door assembly removal (5230n/dn, 5350dn, and
5530dn)” on page 4-43.
1 Check the operator panel assembly (5230n/dn, 5350dn, Go to step 3. Go to step 2.
and 5530dn) or the NVM card assembly (T656 only).
assembly (5230n/dn, 5350dn, and 5530dn) or the NVM
card assembly (T656 only) with a new and not previously
installed operator panel assembly. Go to “Operator panel
door assembly removal (5230n/dn, 5350dn, and
5530dn)” on page 4-43.
