Dell 5230dn Mono Laser Printer - Bin Mailbox Controller Card Assembly Removal

Repair Information 4-93
5-bin mailbox controller card assembly removal
1. Remove the 5-bin mailbox left outer cover. Go to “5-bin mailbox left outer cover removal” on page 4-86.
2. Disconnect all the harnesses from the 5-bin mailbox controller card assembly.
3. Remove the two screws (A) securing the controller card assembly to the 5-bin mailbox assembly.
4. Remove the 5-bin mailbox controller card assembly.
A
