Repair Information 4-79
NVM card assembly removal
WARNING: When replacing any of the following components:
• NVM card assembly (T656 only)
• System card assembly (All models)
2. Remove the six screws (A) securing the metal shield to the machine.
3. Slide the metal shield in the direction of the arrow.
1. Remove the side cover, left. Go to “Side cover, right removal (5230n/dn)” on page 4-67 or “Side cover,
left removal (5350dn, 5530dn, and T656)” on page 4-67.
• Operator panel assembly (5230n/dn, 5350dn, and 5530dn)
To Next Page
