General information 1-3

Printer configurations

Basic model

The following illustration shows the basic printer model.

Feature Paper Capacity

1

1 Standard exit bin 250- or 550-sheet

2 Printer control panel NA

3 Multipurpose feeder 100 sheets

4 Standard tray (Tray 1) 250- or 550-sheets

1

Based on 75 g/m

2

(20 lb.) paper.

1

2

3

4
