Repair Information 4-67
1. Open the MPF tray door assembly.
2. Open the operator panel door assembly.
4. Remove the four screws (A) securing the side cover, left to the machine.
5. Swing the side cover, left away from the machine.
6. Remove the side cover, left.
1. Open the operator panel door assembly.
2. Open the MPF tray door assembly.
page 4-12.
Side cover, left removal (5350dn, 5530dn, and T656)
Side cover, right removal (5230n/dn)
3. Remove the cover assembly, rear lower. Go to “Cover assembly, rear lower removal (5230n/dn)” on
page 4-12 or “Cover assembly, rear lower (5350dn and 5530dn)” on page 4-12.
3. Remove the cover assembly, rear lower. Go to “Cover assembly, rear lower removal (5230n/dn)” on
