Dell 5230dn Mono Laser Printer - High Capacity Stacker Right Cover Removal

Repair Information 4-135
High capacity stacker right cover removal
1. Remove the high capacity stacker rear door assembly. Go to “High capacity stacker rear door assembly
removal” on page 4-134.
2. Using a #1 phillips screwdriver, remove the three screws (A) securing the right cover to the high capacity
stacker assembly.
3. Remove the right cover.
A
