Dell 5230dn Mono Laser Printer - Sensor (Duplex Input) Removal (5350 Dn, 5530 Dn, and T656)

Repair Information 4-69
2. Release the hooks (A) securing the senor (duplex media path) to the bracket.
3. Remove the sensor (duplex input).
A
Sensor (duplex input) removal (5350dn, 5530dn, and T656)
5530dn, and T656)” on page 4-19.
1. Remove the duplex input sensor assembly. Go to “Duplex input sensor assembly removal (5350dn,
