Dell 5230dn Mono Laser Printer - Bin Mailbox Transport Solenoid Removal

Repair Information 4-99
5-bin mailbox transport solenoid removal
1. Remove the 5-bin mailbox left outer cover. Go to “5-bin mailbox left outer cover removal” on page 4-86.
2. Disconnect J15 at the controller card.
3. Remove the screw (A) securing the 5-bin mailbox transport solenoid to the left frame.
4. Remove the 5-bin mailbox transport solenoid.
A
