4-98 Service Manual

4. Remove the screw (A) securing the appropriate 5-bin mailbox deflector gate solenoid.

5. Remove and unroute the cable to the deflector gate solenoid.

6. Disconnect the proper deflector gate solenoid harness from the controller card.

Note: To ease the cable unrouting, cut the appropriate cable.

A
