Dell 5230dn Mono Laser Printer - Fully Configured Model

1-4 Service Manual
Fully configured model
The following illustration shows the fully configured printer model.
CAUTION: – TIPPING HAZARD: Floor-mounted configurations require additional
furniture for stability. You must use either a printer stand or printer base if you are using
a 2000-sheet tray, a duplex unit, and an input option, or more than one input option.
3
4
5
6
7
9
8
1
2
