Diagnostic aids 3-61
Printer theory
PC cartridge
Sensor (input)
PC drum
Standard bin full actuator
and sensor (standard bin full)
Diverter
Sensor (duplex input)
Sensor (fuser output)
Sensor (narrow media)
Sensor (duplex
double feed)
Sensor (duplex exit)
Pick arm
assembly
Sensor (option
pass through)
Model 5230n/dn with duplex, paper path, rolls, and sensors
