4-168 Service Manual
2. Remove the screw (A) on the back side of the option.
3. Remove the grounding screw (B) on the right output option frame guide the grounding cable through the
hole in the frame.
4. Carefully flex the panel from the lower middle and pull the four tab (C) out of the frame and remove.
A
