Parts catalog 7-5
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
7 40X4494 1 1 LCD screen bezel (T652n)
7 40X4628 1 1 LCD screen bezel (T654n)
7 40X7043 1 1 LCD screen bezel (TG654dn)
8 40X5746 1 1 Operator panel bezel, left
8 40X5729 1 1 Operator panel bezel, left (NON USB)
Warning: When replacing any of the following components:
• Operator panel assembly
• System card assembly
Only replace one component at a time. Replace the required component and perform a POR before replacing a second
component listed above. If this procedure is not followed, the printer will be rendered inoperable. Never replace two or
more of the components listed above without a POR after installing each one or the printer will be rendered inoperable.
Never install and remove components listed above as a method of troubleshooting components. Once a component has
been installed in a machine, it can not be used in another machine. It must be returned to the manufacturer.
Assembly 2: 5230n/dn, 5350dn, and 5530dn Operator panel
1 40X4366 1 1 Operator panel cable assembly (5230n/dn, 5350dn, and 5530dn)
2 40X4462 1 1 Operator panel door assembly (5230n/dn, 5350dn, and 5530dn)
3 40X4380 2 1 Counterbalance spring (5230n/dn, 5350dn, and 5530dn)
4 40X4397 1 1 Operator panel hinge assembly, right (5230n/dn, 5350dn, and 5530dn)
5 40X4616 1 1 Operator panel latch assembly (5230n/dn, 5350dn, and 5530dn)
6 40X4396 1 1 Operator panel hinge assembly, left (5230n/dn, 5350dn, and 5530dn)
9 40X4377 1 1 USB cable assembly (5230n/dn, 5350dn, and 5530dn)
7 40X4471 1 1 LCD screen bezel (5350dn)
7 40X4627 1 1 LCD screen bezel (5530dn)
7 40X4415 1 1 LCD screen bezel (5230n/dn)
