Parts catalog 7-7
Assembly 3: T656 Operator panel, MPF and smart card
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X7039 1 1 Card reader cable assembly (T656)
2 40X1972 1 1 Inner cover, right (T656)
3 40X2045 1 1 Operator panel cable assembly (T656)
4 40X2089 1 1 MPF tray door assembly (T656)
5 40X2077 2 1 Counterbalance spring (T656)
6 40X2078 2 1 Spring connector (T656)
7 40X4631 1 1 Operator panel door latch assembly (T656)
8 40X2051 1 1 USB cable assembly (T656)
9 40X1971 1 1 Inner cover, left (T656)
10 40X7038 1 1 Operator panel bezel (T656)
11 40X1385 1 1 Operator panel door assembly (T656)
12 40X7035 1 1 Hard drive cooling fan (T656)
13 40X7042 1 1 Card reader mounting bracket (T656)
14 40X4602 1 1 Card reader assembly (3121 contact) (T656)
14 40X4603 1 1 Card reader assembly (5121 contact/RFID) (T656)
14 40X4604 1 1 Card reader assembly (5125 contact/HID) (T656)
15 40X7037 1 1 Card reader cable assembly (T656)
