Parts catalog 7-9
Assembly 4: Drive motor assemblies and duplex
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
17 99A0954 1 1 Bevel gear with grease packet and washer
• Bevel gear (1)
• Instruction sheet (1)
• Grease packet (1)
18 40X5749 1 1 Main drive motor assembly with option drive shaft
19 40X4386 1 1 Fuser drive release linkage
and T656)
1 40X4465 1 1 Redrive assembly (5230n/dn)
15 40X1863 1 2 Option drive shaft with spring (5230n/dn)
14 40X4302 1 3 Aligner assembly with ground strap and adj. screw (5230n/dn)
14 40X4303 1 3 Aligner assembly with ground strap and adj. screw (5350dn, 5530dn, and
2 40X4344 1 1 Duplex drive motor assembly (5350dn, 5530dn, and T656)
3 40X4346 1 5 Duplex assembly with 2 belts and 2 pulleys (5350dn, 5530dn, and T656)
4 40X4351 1 1 Duplex guide handle (5350dn, 5530dn, and T656)
5 40X4352 1 1 Duplex guide, rear (5350dn, 5530dn, and T656)
6 40X4353 1 1 Duplex guide spring, rear (5350dn, 5530dn, and T656)
7 40X4349 1 1 Duplex guide spring, right (5350dn, 5530dn, and T656)
8 40X4348 1 1 Duplex guide assembly, front (5350dn, 5530dn, and T656)
9 40X5551 1 1 Duplex guide spring, left (5350dn, 5530dn, and T656)
10 40X4369 1 1 Sensor (duplex input) (5350dn, 5530dn, and T656)
11 40X4345 1 1 Duplex (input) sensor assembly (5350dn, 5530dn, and T656)
12 40X4350 1 1 Duplex drive belt, lower (5350dn, 5530dn, and T656)
13 40X4354 1 1 Duplex drive belt, upper (5350dn, 5530dn, and T656)
16 40X4473 1 2 Option drive shaft with spring (5350dn, 5530dn, and T656)
20 40X4343 1 1 Redrive motor assembly (5350dn, 5530dn, and T656)
1 40X4466 1 1 Redrive assembly (5350dn)
1 40X4467 1 1 Redrive assembly (5530dn and T656)
