Dell 5230dn Mono Laser Printer - Page 533

Parts catalog 7-11
Assembly 5: Media path and ducts
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X4384 1 1 EP cooling fan duct
2 40X4390 4 1 Machine pad
3 40X1869 1 1 Transfer deflector with static brush
6 40X1900 1 1 Media turn guide with actuator
7 40X4385 1 1 Envelope feeder interface cover
8 40X4406 2 1 Print cartridge support roller
9 40X1868 2 1 Print cartridge clamp assembly
10 40X4389 1 1 LVPS cooling duct
5 40X4387 1 1 Inner deflector (5230n/dn)
11 40X4391 1 1 Main cooling duct (5230n/dn)
12 40X4319 1 1 Fuser access door assembly (5230n/dn)
5 40X4388 1 1 Inner deflector (5350dn, 5530dn, and T656)
11 40X4392 1 1 Main cooling duct (5350dn, 5530dn, and T656)
12 40X4318 1 1 Fuser access door assembly (5350dn, 5530dn, and T656)
4 40X1889 1 1 Duplex deletion assembly (5350dn and 5530dn)
