Parts catalog 7-15
Assembly 7: Pick arm assembly, trays, and MPF
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X4394 1 1 Tray catch spring
2 40X4395 1 1 Tray roller catch assembly
3 40X4365 1 1 MPF pick solenoid assembly
4 40X4457 1 1 MPF cam gear
5 40X1883 4 1 MPF pick roll assembly with flanges and clip
8 40X4313 1 1 Pick arm sensor cable assembly
11 40X4308 1 2 Pick roll assembly (2)
13 40X4468 1 1 Media tray assembly, 250 sheet
13 40X4469 1 1 Media tray assembly, 550 sheet
14 40X4472 1 1 Switch (media size) assembly
17 40X1876 1 1 MPF gear shield
6 40X4458 1 1 MPF lift plate assembly (5230n/dn)
7 40X4460 1 1 MPF tray door assembly (5230n/dn)
9 40X4304 1 1 Pick arm assembly with spring, 250 sheet (5230n/dn)
10 40X4306 1 1 Pick arm spring (5230n/dn)
12 40X4309 1 1 250 Sheet media out actuator (5230n/dn)
6 40X4459 1 1 MPF lift plate assembly (5350dn, 5530dn, and T656)
9 40X4305 1 1 Pick arm assembly with spring, 500 sheet (5350dn, 5530dn, and T656)
15 40X4307 1 1 Pick arm spring (5350dn, 5530dn, and T656)
16 40X4310 1 1 550 Sheet media out actuator (5350dn, 5530dn, and T656)
7 40X4461 1 1 MPF tray door assembly (5350dn)
7 40X1884 1 1 MPF tray door assembly (5530dn)
