Parts catalog 7-37
Assembly 18: 5-bin mailbox #2
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X5550 1 1 Complete 5 bin mailbox unit assembly
2 40X0028 1 1 Spring (top)
3 40X2036 1 1 Deflector gate (top)
4 40X4772 1 1 Static brush mylar assembly
5 40X2037 1 1 Deflector gate
6 40X2065 1 1 Spring
7 40X3242 1 1 Sensor (pass through)
8 40X2061 5 1 Deflector gate solenoid
9 40X4369 1 1 Sensor (deflector gate HP)
10 40X3240 1 1 Sensor (media bin empty)
11 40X2038 1 1 Media bin full actuator
12 40X5718 1 1 5 bin mailbox controller card assembly
