Dell 5230dn Mono Laser Printer - Page 561

Parts catalog 7-39
Assembly 19: High capacity stacker
Asm-
Index
Part
number
Units/
mach
Units/ kit
or pkg
Description
1 40X5730 1 1 Complete high capacity stacker assembly
2 40X5737 1 1 Rear door assembly
3 40X1988 1 1 Deflector gate
4 40X3264 2 1 Sensor (pass through)
5 40X5733 1 1 High capacity output controller card assembly
6 40X5734 1 1 Right frame
7 40X5735 1 1 Right cover
8 56P4210 1 2 Media output bin recoil spring
9 40X4773 1 1 Standard output bin LED
10 40X5755 1 1 LED clear lens
11 40X5731 1 1 Media output bin assembly
12 40X1998 1 1 Media bail assembly
13 40X4369 1 1 Sensor (deflector gate HP)
14 40X5748 1 1 Left frame
15 56P4208 1 1 Switch (media bin HP)
16 40X5736 1 1 Left cover
17 40X1989 1 1 Sensor bracket
18 40X3265 1 1 Sensor (media bin full assembly)
19 56P4212 1 1 Media bin full actuator
20 40X0028 1 1 Spring (top)
