Delta DVP-15MC Series User Manual

Chapter 11 Motion Control Instructions
11-261
11
from the current position.
 Absolute mode example:
The initial positions of axis X, Y are both 10000 units and their axis parameters are both default
values.
The G codes to be executed are:
N0 G90
N1 G0 X50000 Y100000
 After G codes are executed, the Y/X curve for the whole movement process is shown
below:
O
Y
50000
100000
Position
Position
10000
10000
X
 After G codes are executed, the Position/Time curve for the whole movement process is
shown below:
O
Y
50000
100000
Position
t
X
10000
