Chapter 11 Motion Control Instructions

11-351

1. The variable table and program

Variable name

Data type

Initial value

ADDAXIS1

DMC_AddAxisToGroup

ADDAXIS1_Ex

BOOL

ADDAXIS1_Done

BOOL

ADDAXIS1_Bsy

BOOL

ADDAXIS1_Err

BOOL

ADDAXIS1_ErrID

WORD

ADDAXIS2

DMC_AddAxisToGroup

ADDAXIS2_Done

BOOL

ADDAXIS2_Bsy

BOOL

ADDAXIS2_Err

BOOL

ADDAXIS2_ErrID

WORD

DMC_GroupEnable0

DMC_GroupEnable

GE_En

BOOL

GE_Vel

ARRAY [1..8] OF LREAL

GE_Acc

ARRAY [1..8] OF LREAL

GE_Dec

ARRAY [1..8] OF LREAL

GE_Jerk

ARRAY [1..8] OF LREAL

GE_Status

BOOL

GE_Bsy

BOOL

GE_Abt

BOOL

GE_Err

BOOL

GE_ErrID

WORD

LINABS1

DMC_MoveLinearAbsolute

LINABS1_Ex

BOOL

LINABS1_Pos

ARRAY [1..8] OF LREAL

LINABS1_Done

BOOL

LINABS1_Bsy

BOOL

LINABS1_Act

BOOL

LINABS1_Abt

BOOL

LINABS1_Err

BOOL

LINABS1_ErrID

WORD

LINABS2

DMC_MoveLinearAbsolute

LINABS2_Pos

ARRAY [1..8] OF LREAL

LINABS2_Done

BOOL

LINABS2_Bsy

BOOL

LINABS2_Act

BOOL

LINABS2_Abt

BOOL

LINABS2_Err

BOOL

LINABS2_ErrID

WORD
