Parameter
name
Function Data type
Valid range
(Default)
Validation timing
TransitionPar
ameter
Set the transition
parameter for specific
transition mode
LREAL
Positive number, 0
（0）
When Execute
changes from
FALSE to TRUE.
Note:
1. DMC_MoveCircularRelative instruction starts being executed when Execute changes from FALSE to
TRUE. Changing Execute from TRUE to FALSE during the instruction execution will have no impact
on the instruction execution.
2. When drawing an arc by adopting the center method, the values of AuxPoint[1] and AuxPoint[2] are
the coordinate differences between the center and start point of an circular arc. When drawing an arc
by adopting the radius method, the value of the input AuxPoint[1] is the radius. The value of AuxPoint[2]
is meaningless.
3. The value of input parameter EndPoint[1]~EndPoint[8] means the coordinate diferences between end
point and start point on axes.
4. Refer to section 10.2 for the relationship among Velocity, Acceleration, Deceleration and Jerk .
5. For details on BufferMode, refer to section 10.3.
 Output Parameters
Parameter name
Function
Data type
Valid range
Done
TRUE when the instruction execution is
completed.
BOOL TRUE / FALSE
Busy
TRUE when the instruction is being executed.
BOOL
TRUE / FALSE
Active
TRUE when the instruction is controlling the axes
group.
BOOL TRUE / FALSE
CommandAborted
TRUE when the instruction execution is aborted.
BOOL
TRUE / FALSE
Error
TRUE when an error occurs in execution of the
instruction.
BOOL TRUE / FALSE
ErrorID
Contains the error code when an error occurs.
Please refer to section 12.2.
WORD
 Output Update Timing
Name
Timing for changing to
TRUE
Timing for changing to FALSE
Done
 When the end
positions are reached.
 When Execute changes from TRUE to FALSE after the
instruction execution is completed
 Done changes to TRUE when the instruction execution
is completed after Execute changes from TRUE to
FALSE during the instruction execution. One cycle later,
Done changes to FALSE.
Busy
 When Execute
changes to TRUE.
 When Done changes to TRUE
 When Error changes to TRUE
 When CommandAbort changes to TRUE
Active
 When axes start being
controlled by the
insruction.
 When Done changes to TRUE
 When Error changes to TRUE
 When CommandAbort changes to TRUE
