10.4 Modbus Test
This is the menu to check and test Modbus signals set at Modbus TCP, Modbus RTU, and predefined Modbus.
No.
Item
Description
1
Modbus Type
Select the Modbus type to check. TCP, RTU, and predefined Modbus
are available.
2
Slave
Displays the list of IPs/Ports of the slave set of the selected Modbus
type. When selected, it displays a list of corresponding signals.
3
Signal List
Displays a list of signals set on the selected slave. Input and output
signals can be checked.
1
2
3
