Doosan H2017 - System Operation Program Outline

63
5. System Operation Program Outline
The UI of the system operation program consists of the following:
No.
Item
Description
1
Status Display
Area
This area displays the name of the task currently being executed and
the current work status.
2
Work Screen Area
This area is where the user enters and changes settings when
performing work using the robot. This area is displayed differently
according to the selected main menu.
3
Main Menu Area
This area is the main menu of the system, and pressing each menu
will go to the corresponding screen.
1
2
3
