Chapter 12
| Link Aggregation Commands
Manual Configuration Commands
– 446 –
â–
src-mac: All traffic with the same source MAC address is output on the
same link in a trunk. This mode works best for switch-to-switch trunk links
where traffic through the switch is received from many different hosts.
Example
Console(config)#port-channel load-balance dst-ip
Console(config)#
channel-group This command adds a port to a trunk. Use the no form to remove a port from a
trunk.
Syntax
channel-group channel-id
no channel-group
channel-id - Trunk index (Range: 1-16)
Default Setting
The current port will be added to this trunk.
Command Mode
Interface Configuration (Ethernet)
Command Usage
â—† When configuring static trunks, the switches must comply with the Cisco
EtherChannel standard.
â—† Use no channel-group to remove a port group from a trunk.
â—† Use no interface port-channel to remove a trunk from the switch.
Example
The following example creates trunk 1 and then adds port 10:
Console(config)#interface port-channel 1
Console(config-if)#exit
Console(config)#interface ethernet 1/10
Console(config-if)#channel-group 1
Console(config-if)#
