Chapter 12
| Link Aggregation Commands
Trunk Status Display Commands
– 454 –
Console#show lacp 1 neighbors
Port Channel 1 neighbors
-------------------------------------------------------------------------
Eth 1/ 1
-------------------------------------------------------------------------
Partner Admin System ID : 32768, 00-00-00-00-00-00
Partner Oper System ID : 32768, 00-12-CF-61-24-2F
Partner Admin Port Number : 1
Partner Oper Port Number : 1
Port Admin Priority : 32768
Port Oper Priority : 32768
Admin Key : 0
Oper Key : 3
Admin State: defaulted, distributing, collecting,
synchronization, long timeout,
Oper State: distributing, collecting, synchronization,
aggregation, long timeout, LACP-activity
.
.
.
Admin State,
Oper State
Administrative or operational values of the actor’s state parameters:
â—†
Expired – The actor’s receive machine is in the expired state;
â—†
Defaulted – The actor’s receive machine is using defaulted operational
partner information, administratively configured for the partner.
â—†
Distributing – If false, distribution of outgoing frames on this link is
disabled; i.e., distribution is currently disabled and is not expected to be
enabled in the absence of administrative changes or changes in received
protocol information.
â—†
Collecting – Collection of incoming frames on this link is enabled; i.e.,
collection is currently enabled and is not expected to be disabled in the
absence of administrative changes or changes in received protocol
information.
â—†
Synchronization – The System considers this link to be IN_SYNC; i.e., it has
been allocated to the correct Link Aggregation Group, the group has been
associated with a compatible Aggregator, and the identity of the Link
Aggregation Group is consistent with the System ID and operational Key
information transmitted.
â—†
Aggregation – The system considers this link to be aggregatable; i.e., a
potential candidate for aggregation.
â—†
Long timeout – Periodic transmission of LACPDUs uses a slow transmission
rate.
â—†
LACP-Activity – Activity control value with regard to this link.
(0:Passive;1:Active)
Table 79: show lacp neighbors - display description
Field Description
Partner Admin
System ID
LAG partner’s system ID assigned by the user.
Partner Oper
System ID
LAG partner’s system ID assigned by the LACP protocol.
Partner Admin
Port Number
Current administrative value of the port number for the protocol Partner.
Partner Oper
Port Number
Operational port number assigned to this aggregation port by the port’s
protocol partner.
Table 78: show lacp internal - display description (Continued)
Field Description
