Chapter 2 | Installation Overview
Switch Installation Tasks
– 22 –
Go to the chapter “Port Connections”
Figure 8: Making a Connection to an RJ-45 Port
10/100/1000BASE-T RJ-45 Port.
Twisted-pair Cable with RJ-45 Plug.
1
2
1
2
