FOR RESTRICTED USE only Fargo Electronics, Inc.
DTC550 Direct to Card Printer/Encoder User Guide (Rev. 2.8)
3-16
Loading the Overlaminate (continued)
Step Procedure
5 a. Place the supply end of the overlaminate roll in between the two black
Lamination Drive Hubs.
b. Use the end of the supply roll with the black core plug to push in the spring
loaded hub located on the front side of the Printer. (Note: Make certain
the overlaminate material is fed from beneath the roll, as shown below.)
To Next Page
