Specifications
611
Appendix
16
îš„ HCF2 (2000 sheets) (optional)
îš„HCF B1-S
Inserter Paper size : Maximum: A3, 11 × 17",
Minimum: B5
Important • You cannot copy on the paper loaded in inserter.
Capacity : 200 sheets
Important • When using 80 gsm paper
Paper type : 64 - 220 gsm
Power Supply/Power
Consumption
220 - 240V AC ±10%/110V ±10%, 2A for both 50/60 HZ ± 3%
Maximum Power Consumption: 200W
Dimensions/Weight Width 1,050 × Depth 725 × Height 1,165 mm, 135 kg
When D2 Folder Unit is installed :
Width 1,250 × Depth 725 × Height 1,165 mm, 175 kg
Note • This weight includes the staple cartridge.
Space Requirement Width 2,230 × Depth 804 mm (main unit + Finisher D2-P with
Booklet Maker (when D2 Folder Unit is installed), when the
Middle Size Color UI is installed, and the bypass tray and the
extension tray are fully extended)
Width 2,425 × Depth 781 mm (main unit + Finisher D2-P with
Booklet Maker (when D2 Folder Unit is installed), when the
Large Size UI Kit is installed, and the bypass tray and the
extension tray are fully extended)
Paper Size / Paper
Weight
Maximum: A4 , Minimum: B5
64 - 220 gsm
Paper Capacity /
Number of Trays
2,000 sheets × 1 tray
Important • When using 80 gsm paper
Dimensions/Weight Width 389 × Depth 610 × Height 377 mm, 29 kg
Space Requirement Width 1,574 × Depth 804 mm (main unit + HCF2 (2000 sheets),
when the bypass tray and the extension tray are fully
extended)
Paper Size / Paper Type Standard Size:
Maximum: A3, 12.6 × 19.2", 13 × 19"
Minimum: postcards
*1
Non-Standard Size:
182 (Y direction) × 182 (Y direction) mm - 330 (Y direction) × 488
mm (X direction)
*2
64 - 300 gsm
*1: When the Post Card Kit is used
*2: When the length (Y direction) of non-standard size paper is 100 to 181 mm the Post
Card Kit must be used.
Paper Capacity /
Number of Trays
2,000 sheets × 1 tray
Important • When using 80 gsm paper
Power Supply/Power
Consumption
220 - 240V AC ±10%/110V ±10%, 2.5A for both 50/60 HZ ± 3%
Dimensions/Weight Width 988 × Depth 762 × Height 992 mm, 160 kg*
* The bypass tray and the Large Size UI Kit are not included.
Space Requirement Width 2,045 × Depth 804 mm (main unit + HCF B1-S, when the
extension tray are fully extended)
