Troubleshooting 374
îš„ Identifying the Location of Paper Jams
IMPORTANT:
• Do not attempt to clear any jams using tools or instruments. This may permanently damage the printer.
The following illustration shows where paper jams may occur along the print media path.
• Do not attempt to remove a paper jammed deeply inside the product, particularly a paper wrapped
around a Fuser Unit or a heat roller. Otherwise, it may cause injuries or burns. Switch off the product
promptly and contact your local Fuji Xerox representative.
1 Automatic Document Feeder (ADF)
2 Duplexer
3 Fuser Unit
4 Optional 250-Sheet Feeder
5 Single Sheet Feeder (SSF)
6 Standard 250-Sheet Tray
7 Front Cover
