83 Network Basics
îš„ Assigning an IP Address (for IPv4 Mode)
NOTE:
• When you assign an IP address manually in IPv6 mode, use the CentreWare Internet Services. To display the
CentreWare Internet Services, use the link local address. To check a link local address, see "Printing and
Checking the System Settings Page" on page 86.
• Assigning an IP address is considered as an advanced function and is normally done by a system
administrator.
• Depending on the address class, the range of the IP address assigned may be different. On Class A, for
example, an IP address in the range from 0.0.0.0 to 127.255.255.255 will be assigned. For
assignment of IP addresses, contact your system administrator.
You can assign the IP address by using the operator panel.
1 Turn on the printer.
Ensure that Ready message appears on the LCD panel.
2 On the operator panel, press the System button.
3 Select Admin Menu, and then press the button.
4 Select Wired Network, and then press the button.
5 Select TCP/IP, and then press the button.
6 Select IPv4, and then press the button.
7 Select Get IP Address, and then press the button.
8 Select Panel, and then press the button.
9 Ensure that the message This Setting Becomes Effective after Restart appears,
and then press any button.
10 Press the button to select IP Address, and then press the button.
The cursor is located at the first octet of the IP address.
11 Enter the value of the IP address using the numeric keypad.
12 Press the button.
The cursor moves to the next octet.
13 Repeat steps 11 to 12 to set all of the digits in the IP address, and then press the button.
14 Ensure that the message This Setting Becomes Effective after Restart appears,
and then press any button.
15 Press the button to select Subnet Mask, and then press the button.
The cursor is located at the first octet of the subnet mask.
16 Enter the value of the subnet mask using the numeric keypad.
17 Press the button.
The cursor moves to the next octet.
18 Repeat steps 16 to 17 to set subnet mask, and then press the button.
To Next Page
