41 Basic Operation
Front View
1 Operator Panel 2 Front USB Port
3 Document Feeder Tray 4 Document Output Tray
5 Output Tray 6 Side Button
7 Power Switch 8 Toner Cartridge
9 Side Cover 10 Standard 250-Sheet Tray
11 Optional 250-Sheet Feeder 12 Width Guides
13 Single Sheet Feeder (SSF) 14 Front Cover
15 Fuser Unit 16 Drum Cartridge
17 Belt Unit 18 Duplexer
