TX1330 M1 Upgrade and Maintenance Manual 299
Converting a tower model to a rack model
Ê Firmly press down on the rack mounting bracket until it is fully seated in the
rack front bezel (2).
Ê Mount the second rack mounting bracket accordingly.
Figure 201: Installing accessible drive dummy covers
Ê If available, reinstall all accessible drive dummy covers into their original
locations (rotated by 90 degrees):
Ê Ensure that an accessible drive filler cover has been installed in every
empty drive bay.
Ê Turn the front cover face down.
Ê Join the two lugs on one edge of the accessible drive cover with the right
inner edge of the front cover (1).
Ê Fold down the accessible drive cover until it snaps in place (2).
I Use the dummy covers that have been removed from the front cover
during the preliminary steps.
Ê Install the rack front cover as described in section "Installing the rack front
cover" on page 58.

Fujitsu Server PRIMERGY TX1330 M1 Specifications

General

Memory Slots	4
Form Factor	Tower
Chipset	Intel C226
Processor Sockets	1
Processor	Intel Pentium, Intel Celeron
RAID Support	RAID 0, 1, 5, 10
Drive Bays	8 x 3.5-inch
Operating System Support	Windows Server, Red Hat, SUSE, VMware
