TX1330 M1
Upgrade and Maintenance Manual 309
Cabling
Figure 209: Riser card cabling - 1
PSU
Front Panel
Drive Bay 1
SATA ODD
Drive Bay 2
USB Backup Drive
Drive Bay 3
SAS Backup Drive
X9
X9
HDD Backplanes
3.5” HDD BP
2.5” HDD BP 1
System Board D3239
32-bit PCI Riser Card
PCI Slot 1
11
