GE LOGIQ P6 Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 5-36 Section 5-1 - Overview
5-8-2 System Checkout Procedure (cont’d)
All bold fields should be filled
7.) Device Name and CRM No are pre-populated and can not be changed.
8.) Select Continent and Country.
9.) Put City, State, and Institution.
10.)Select “Product” for the Enterprise.
11.)If Proxy needs to be configured, select “Enable” for the Proxy filed and input IP address and Port
number.
12.)Press “Submit Changes”. “Please Wait” message is displayed while the system is checking out.
Figure 5-37 Please Wait

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
