GE LOGIQ P6 Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 7 - Page 7-41
7-9-11 Network Troubleshooting (cont’d)
Figure 7-25 Network Troubleshooting
No Connection to the Network
Connect the cable and verify that it is
well seated in both ends.
YES
NO
Is the
TCP/IP Cable between
LOGIQ™ P6/P6 Pro and
network outlet connected
and well
Replace the AEXP cable between
SYSCONML and P6 ARP assy
YES
Is the connection OK now?
NO
Connect a Crossed Network Cable
between the Scanner and your PC/
Laptop.
Try to ping from the PC/Laptop to
LOGIQ™ P6/P6 Pro.
If OK, the hardware connection
inside LOGIQ™ P6/P6 Pro is OK.
Try a network cable that is known to
be OK
NO
Is the cable between
SYSCONML assy and P6
APR Assy OK?
YES
Replace the P6 ARP assy.

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
