LOGIQ™ P6/P6 PRO SERVICE MANUAL
Page 8-112 Section 8-4 - Software Installation
8-4-1 Installing Base Image Software (cont’d)
4.) If the BIOS setting value in Primary IDE Slave is ATAPI CDROM, the 1st Boot Device in Boot
menu should be Primary Slave. If the 1st Boot Device is not Primary Slave, please change the
setting value using Enter key and Arrow key.
5.) If the BIOS setting value in Secondary IDE Master is ATAPI CDROM, the 1st Boot Device in Boot
menu should be Secondary Master. If the 1st Boot Device is not Secondary Master, please change
the setting value using Enter key and Arrow key.
Figure 8-165 Boot Device Priority
Figure 8-166 IDE Configuration

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
