GE LOGIQ P6 Series User Manual

GE HEALTHCARE
DIRECTION 5394152, Revision 5
LOGIQ™ P6/P6 PRO SERVICE MANUAL
Chapter 8 - Page 8-129
8-4-4-3 Setting Printer Preferences (cont’d)
9.) Click “Load”.
10.)Select removable disk or media which the printer setting was saved -> click “Open.
11.)Click the “OK” until all printer windows are closed.
12.)If the printer is not support restore option, restore the printer set from the recorded parameters.
NOTE: The parameters depend on printers, so the above parameters are shown to another names and
more parameters setting could be needed.
Figure 8-192 Printer set restore
Parameters Descriptions
Orientation Portrait or Landscape
Paper size Paper size
Scaling Rate of length and width
Density AdjustGamma curve
Table 8-51 Parameters

GE LOGIQ P6 Series Specifications

General

Power Supply	100-240 VAC, 50/60 Hz
Imaging Modes	B-Mode, M-Mode, Color Doppler, Power Doppler
Applications	Vascular, Musculoskeletal
Operating Temperature	10°C to 40°C
Display	15-inch LCD
Relative Humidity	20% to 80% (non-condensing)
