LOGIQ™ P6/P6 PRO SERVICE MANUAL

Chapter 8 - Page 8-173

8-7-11 Color Printer Fixture Top Installation - UP-D25MD Printer (cont’d)

7.) Connect the USB cable and Power Cable to the system.

8.) Tie the cables using the tie wrap.

Figure 8-274 Color Printer Fixture Top Installation
